Op Amp Boost Board

Pre/Post Op Amp Boost Board Build a single op amp boost circuit using the Stompbox Electronics Pre/Post Op Amp Boost board! Only the circuit board is included in this purchase. All components must be surface-mount except for the potentiomter. See below for suggested component parts and where to source them. Whether you’re building a boost pedal or modifying an existing circuit to fix a volume drop, the Op Amp Boost Board is a natural solution. Contents hide Pre/Post Op Amp Boost Board What is an Op Amp Boost? What parts will I need and where do I get them? Where can I get support? Which tools will I need to build the mod board? Are there refunds? Sponsor Acknowledgement What is an Op Amp Boost? An Op Amp Boost is a circuit that increases the amplitude of an audio signal. Using a single op amp and a handful of components, you can create your own op amp boost circuit. What parts will I need and where do I get them? Resistors are all standard values and are 0805 (0.080″ x 0.050″) SMD packages. You can find them in most 0805 SMD resistor kits (Amazon). The recommended values for R1 – R6 are: R1  47k R2  47k R3  470k R4  47k R5  1M R6  10k The capacitors are both recommended to be 104 (100nF). They should also be 0805 packages and can be found in most 0805 SMD capacitor kits (Amazon). As for the potentiometer for gain control, you can use a standard 100k ohm linear pot. LoveMySwitches usually stocks them. The op amp is a single SOIC-8 package. The recommended op amp is the TL071CDR from Mouser. Where can I get support? If you need support, you may choose to e-mail me at [email protected]. I try to respond to e-mails as soon as I’m able, please be patient! Which tools will I need to build the mod board? You will need solder, a soldering iron, and a handy pair of precision tweezers are enough to build the Op Amp Boost. Are there refunds? Purchase of this board implies you have sufficient knowledge and the skills required to build it. If you feel that you cannot reliably build the board yourself then contact me for support. After purchase of the board I can direct you to any services or resources you might need. Sponsor Acknowledgement   Development of this product is sponsored by:   If you’re interested in having your own Op Amp Boost boards built, visit the link below:   Disclaimers No returns or refunds are accepted for any circuit boards purchased from Stompbox Electronics. As an Amazon Associate and a Reverb Partner, Stompbox Electronics is supported by and earns from qualifying purchases.
