TIANDY 2MP IP POE 8 Camera Packages

Camera Image Sensor 1/3″CMOS Min. Illumination Color:0.04Lux@(F2.2,AGC ON),B/W:0Lux with IR Shutter Time 1s-1/100000s Day&Night IR-cut filter with auto switch (ICR) WDR DWDR S/N >37dB Angle Adjustment 0-360°;0-80°;0-360° Lens Lens Type Fixed Focal Length 2.8mm Lens Mount M12 Aperture Range F2.2,Fixed Field of View 94.4°(H);53.2°(V);108.2°(D) DORI Distance Detect:40.0m Observe:15.9m Recognize:8.0m Identify:4.0m Illuminator IR LEDs 2 IR Distance 30m Wavelength 850nm Compression   Standard Video Compression S 265/H.265/H.264B/H.264M/H.264H Video Bit Rate 32k-4Mbps Audio Compression G.711A/G.711U Audio  Sampling Rate 8kHz Image Max. Resolution 1920×1080@30fps Main Stream PAL:25fps(1920×1080,1280×720,704×576,640×480) NTSC:30fps(1920×1080,1280×720,704×480,640×480) Sub Stream PAL:25fps(704×576,704×288,352×288,640×360) NTSC:30fps(704×480,704×240,352×240,640×360) BLC Yes HLC Yes AGC Yes 3D DNR Yes White Balance Auto/Semi-auto/Manual OSD 1 region;16*16/32*32/48*48 Privacy Mask 4 regions Defog Yes Feature Alarm Trigger Motion Detection Network ANR N/A Protocols HTTP;TCP/IP;UDP;ICMP;DHCP;DNS;NTP;IPv4;Telnet;Unicast System   Compatibility ONVIF Profile S/T Remote Connection 1 Moblie Client N/A Web IE10 ;Firefox52 ;Edge89 ;Safari11 ;Chrome57 Interface Communication   Interface 1 RJ45 10M/ 100M self  adaptive Ethernet port Built-In Mic Yes General Web Client Language English Operating   Temperature -30℃-60℃ Operating Humidity 0-95%(non-condensing) Storage Temperature -30℃-60℃ Storage Humidity 0-95%(non-condensing) Power Supply POE 802.3af;MAX 3W Protection Surge protection  2000V;Lightning proof 6000V;IP67 Boundary Dimensions 140(L)60(W)60(H)mm Package Dimensions 155(L)75(W)85(H)mm GrossWeight 0.2kg NetWeight 0.15kg   Tiandy Poe NVR TC-R3108 is a network video recorder (NVR) supporting up to 8 IP cameras. It features advanced video compression formats including S 265 and H.265, reducing storage space by up to 75%. The device supports up to 6TB HDD capacity and offers simultaneous HDMI and VGA outputs with up to 1080p resolution. It includes 8 PoE Ethernet ports for easy camera connection and power supply. With 4-channel synchronous playback and cloud upgrade support, the TC-R3108 is designed for efficient and flexible surveillance management.   Video and Audio Access Channel 8 Incoming Bandwidth 60Mbps Outgoing Bandwidth 40Mbps Resolution 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF Preview Decoding Capability 6MP(30fps)×1, 5MP(30fps)×1, 4MP(30fps)×2, 3MP(30fps)×2, 1080P(30fps)×4, 720P(30fps)×8, 4CIF(30fps)×8 Playback Decoding Capability 6MP(30fps)×1, 5MP(30fps)×1, 4MP(30fps)×1, 3MP(30fps)×2, 1080P(30fps)×3, 720P(30fps)×4 Third-party Camera Access ONVIF(Profile S/T); RTSP HDMI Output HDMI: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz) VGA Output VGA: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz) Multi-screen Display Simultaneous Output: VGA: 1/2/3/4/5/6/7/8/9 HDMI: 1/2/3/4/5/6/7/8/9 Compression Video S 265; H.265; S 264; H.264 Audio G711A; G711U; ADPCM_DIV4 Stream Type Video; Video & Audio Network Network Protocol ARP; DDNS; DHCP; DNS; Easy DDNS; HTTP; ICMP; IGMP; IPv4; IPv6; NTP; RTCP; RTP; RTSP; SSH; TCP/IP; UDP; Unicast; UPnP Mobile Phone Access Android; iOS; P2P System Compatibility CGI; SDK Web IE10 ; Firefox52 ; Edge89 ; Safari11 ; Chrome57 Record Playback Multi-channel Playback 4 Record Mode Alarm Recording; Schedule Recording Storage Method Local HDD Backup USB storage device Playback Function Play/Pause/Stop/Slow/Speed/Backwards 30s/Forwards 30s/Full Screen/Backup (Video Editing)/Digital Zoom Alarm General Alarm Motion Detection; Mask Alarm; Alarm Input(IPC) Exceptions Alarm Video Loss; Network Disconnected; No Disk; Illegal Access; Disk Full; Disk R/W Error; Recording Abnormal; Abnormal found in smart of disk; Abnormal temperature of the disk; PoE Overload; Voltage Alarm(IPC); RTC Failure; IP Address Conflict; MAC Address Conflict Intelligent Analytics AI by Camera Smart Motion Storage HDD Capacity Up to 6 TB capacity for each HDD External Port USB 2×USB2.0 HDMI 1×HDMI VGA 1×VGA Network Interface 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port SATA 1×SATA interface PoE PoE Interface 8×RJ45, 10/100 Mbps self-adaptive Ethernet port PoE Budget 45W Power per PoE Port 30W Standard IEEE 802.3 af/at General UI Language English; Spanish; Italian; Turkish; French; Polish; Dutch; Hebrew; German; Portuguese Power Supply DC48V Power Consumption <10W(without HDD&without PoE) NetWeight 0.47kg GrossWeight 0.89kg Boundary Dimensions 200(L)200(W)43(H)mm Package Dimensions 315(L)70(W)235(H)mm Operating Temperature -10℃~ 55℃ ( 14℉~ 131℉) Operating Humidity 10%~90%RH (non-condensing) Storage Temperature -20℃~ 60℃ (-4℉~ 140℉) Package Kit Network Video Recorder; Screw Pack; Mouse; European Standard Power Adapter (DC48V 1.35A) Categories: ALL ITEMS, TIANDY IP POE CAMERA (AK SERIES), TIANDY Products
