1SMA12AT3G Tvs Diode ESD Suppressor

1SMA12AT3G is an 19.9V Clamp 20.1A Ipp Tvs Diode Surface Mount SMA ESD Suppressors Unidirectional. The 1SMA5.0AT3G series is designed to protect voltage sensitive components from high voltage, high energy transients. They have excellent clamping capability, high surge capability, low zener impedance and fast response time. The 1SMA5.0AT3G series is supplied in the Littelfuse exclusive, cost-effective, highly reliable package and is ideally suited for use in communication systems, automotive, numerical controls, process controls, medical equipment, business machines, power supplies and many other industrial/consumer applications. Features: Working Peak Reverse Voltage Range − 5.0 V to 78 V Standard Zener Breakdown Voltage Range − 6.7 V to 91.25 V Peak Power − 400 W @ 1 ms ESD Rating of Class 3 (> 16 kV) per Human Body Model Response Time is Typically < 1 ns Flat Handling Surface for Accurate Placement Package Design for Top Slide or Bottom Circuit Board Mounting Low Profile Package Download Data Sheet for 1SMA12AT3G SKU: R02A00113 Category: Diodes
