BZX84-C12 Zener Diode 12V 250mW

Product Overview BZX84-C12 Zener Diode 12V 250mW Low-power voltage regulator diodes in a small SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package. The diodes are available in the normalized E24 ±1 % (BZX84-A), ±2 % (BZX84-B) and approximately ±5 % (BZX84-C) tolerance range. The series includes 37 breakdown voltages with nominal working voltages from 2.4 V to 75 V. Features of BZX84-C12 Zener Diode 12V 250mW Total power dissipation: ≤ 250 mW Three tolerance series: ±1%, ±2% and approximately ±5% AEC-Q101 qualified Working voltage range: nominal 2.4 V to 75 V (E24 range) Non-repetitive peak reverse power dissipation: ≤ 40 W Specifications of BZX84-C12 Zener Diode Type number Package version Package name Size (mm) VZ [nom] (V) IZ (mA) Tolerance /- VZ [min] (V) VZ [max] (V) IF [max] (mA) Ptot (mW) PZSM (W) TJ [max] (°C) Configuration BZX84-C12 SOT23 SOT23 2.9 x 1.3 x 1 12 5 5% 11.4 12.7 200 250 40 150 single Applications General regulation functions Package Includes: 100 Pcs x BZX84-C12 Zener Diode 12V 250mW Download Datasheet For more info click here SKU: REEL-30 x 100 PCs Category: Diodes
