BZV55-C13 Zener Diode 13V 500mW

Product Overview BZV55-C13 Zener Diode 13V 500mW Low-power voltage regulator diodes in small hermetically sealed glass SOD80C Surface-Mounted Device (SMD) packages. The diodes are available in the normalized E24 ±2 % (BZV55-B) and approximately ±5 % (BZV55-C) tolerance range. The series consists of 37 types with nominal working voltages from 2.4 V to 75 V. Features of BZV55-C13 Zener Diode: Non-repetitive peak reverse power dissipation: ≤ 40 W Total power dissipation: ≤ 500 mW Two tolerance series: ±2 % and ±5 % Wide working voltage range: nominal 2.4 V to 75 V (E24 range) Low differential resistance Small hermetically sealed glass SMD package Specifications of BZV55-C13 Zener Diode Type number Package version Package name Size (mm) VZ [nom] (V) IZ (mA) Tolerance /- VZ [min] (V) VZ [max] (V) IF [max] (mA) Ptot (mW) PZSM (W) TJ [max] (°C) Configuration BZV55-C13 SOD80C LLDS; MiniMelf 3.5 x 1.5 13 5 appr. 5% 12.4 14.1 250 500 40 200 single Applications General regulation functions Package Includes: 100 Pcs x BZV55-C13 Zener Diode 13V 500mW Download Datasheet Click here for more info SKU: REEL-29 Category: Diodes
