LINDY 43278 DST-Mini Plus USB-C Laptop Mini Docking Station with …

– Adds 3 USB 3.2 / 3.1 Gen 1 / USB 3.0 Type A ports, an HDMI and VGA port as well as a Gigabit Ethernet port to a laptop– Supports 4K UHD 3840×2160@30Hz for HDMI displays and Full HD 1920×1080@60Hz for VGA displays– Features DisplayPort Alternate Mode– USB Power Delivery 3.0 capable up to 100W– 2 year warranty The DST-Mini Plus with VGA is a compact, multifunctional solution for hybrid workers. Housed in a robust aluminium with a high-quality braided USB-C cable, this dock has been designed for durability during travel. With support for HDMI and VGA, it is ideal for those who have an older legacy monitor they wish to plug their device into. Extended DisplaysThis docking station can support a 4k extended display at 30Hz or 1080p Full HD 60Hz via its HDMI port. It does this through a single USB-C connection using DisplayPort Alternate Mode. Alternatively, you can access crisp 1080p Full HD via the legacy VGA connection. If both video outputs are connected, 1080p Full HD is possible with the displays showing mirroring content Added ConnectivityProviding three SuperSpeed USB Type A ports (5Gbps), Card Readers (SD & microSD), USB-C PD, Gigabit Ethernet, VGA and HDMI, the DST-Mini Plus unlocks a world of connectivity for your device. With a single USB-C connection, you can connect USB accessories such as keyboard and mice as well as expand your storage and take advantage of a lightening quick wired Ethernet connection. Pass-through ChargingThanks to the USB-C Power Delivery, by connecting a USB-C charger to the docking station you can expect up to 100W charging to any connected laptop (depending on the USB-C charger and how much power the dock is using). Simply connect one USB-C cable and be confident that all your connected device will be fully charged and ready to go. Plug-and-PlayThis docking station does not require any driver installation. This allows for seamless large-scale implementation and a hassle-free experience. SpecificationsInterface: USB Type C to 1x VGA / 1x HDMI / 1x RJ45 / 3x USB 3.0 Type A / 1x microSD / 1x SDInterface Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0, VGA, HDMI, Gigabit LANSupported Bandwidth: 5 Gbps, 10/100/1000MbpsMaximum Input Resolution: 3840×2160@30HzMaximum Output Resolution:3840×2160@30Hz (HDMI), 1920×1080@60Hz (VGA)Simultaneous connection with the same video content:1920×1080@60Hz each (VGA / HDMI)Chipset: RTL8153B, EP9632G, GL3510Compatibility: USB Type C or Thunderbolt 3/4 equipped computers with DisplayPort Alternate Mode support. Windows, macOS, Linux, Android, ChromeOSPower Delivery: PD 3.0 up to 100W (20V 5A)HDCP Support: HDCP2.2Supported Audio: –Separate Audio Ports: –Special Features: DisplayPort Alternate Mode ConnectorsInputs: 1 x USB Type C (Male)Outputs: 1x USB Type C (Female), 1x VGA (Female), 1x HDMI (Female), 1x RJ45 (Female), 3x USB Type A (Female), 1x SD slot, 1x microSD slotPower: – Physical PropertiesDimensions WxDxH: 180x17x49mm (7.09×0.67×1.93in)Housing Material: AluminiumNet Weight: 0.09kg (0.2lb)Operating Temperature: 0° – 45°C (32°F – 113°F)Storage Temperature: -20°C – 60°C (-4°F – 140°F)Humidity: 20 – 80% RH (non-condensing)Power Requirements: Bus-poweredColour: Grey MiscellaneousPackaging Type: PolybagPackaging Dimensions: 174x194mm (6.85×7.64in)Gross Weight: 0.1kg (0.22lb)Warranty (Years): 2Certified: CE, UKCA, FCC, REACH & RoHS, CP65 Package contentsUSB 3.2 Type C Laptop Mini Docking StationLindy Manual
