DB107 Bridge Rectifier

Product Overview DB107 Bridge Rectifier typically refers to a single-phase bridge rectifier diode, which is commonly used to convert alternating current (AC) into direct current (DC). The “DB” stands for “Diode Bridge,” and the “107” may be part of the manufacturer’s part number or package type.The  rectifier configuration, which consists of four diodes is arranged in a specific pattern to efficiently convert AC voltage into DC voltage. Features of DB107 Rectifier Glass passivated chip junction High forward surge current capability Ideal for printed circuit board High temperature soldering guaranteed:260℃/10 seconds at terminals Voltage range-50 to 1000 Volts Current- 1.0 Ampere Bridge rectifier diodes are commonly used in power supply circuits to convert AC voltage from a transformer or mains power into a smoother DC voltage suitable for powering electronic devices. Mechanical Data Epoxy: UL94V-0 rate flame retardant Case: Transfer molded plastic Terminals solderable per MIL-STD-202E method 208C Polarity: Molded on body Mounting position: Any Weight-1 gm It’s essential to use the datasheet provided by the manufacturer. The datasheet contains important information about electrical characteristics, pinout, and recommended operating conditions.  Download DB107 Bridge Rectifier Datasheet SKU: FR-97 Category: Diodes
